External sensor

  • Pressure accuracy: +0.1Bar(1.5ps)
  • Temperature Accuracy: +3 C
  • Transmitting power: <8dBm
  • Transmitting frequency: 433.92MHZ
  • Battery life: > 22 years
  • Sensor mass: 8g
  • Sensor size: 20mm*17mm (high diameter)
  • Battery Model: CR1632 (Replaceable Battery)

Built-in sensors

  • Sensor operating temperature: – 40 – 125 C
  • Pressure monitoring range: 0-8Bar (116Psi)
  • Pressure accuracy: +0.1ar(1.5psi)
  • Temperature Accuracy: +3 C
  • Transmit power: < 10dm
  • Transmitting frequency: 433.92MHZ
  • Battery life: > 5 years
  • Sensor mass: 38g
  • Battery model: CR2450HR

External sensor

  • Pressure accuracy: +0.1bar(1.5psi)
  • Temperature Accuracy: +3 C
  • Transmitting power: <8dBm
  • Transmitting frequency: 433.92MHZ
  • Battery life: > 2 years
  • Sensor mass: 6g
  • Sensor size: 17mm*13.5mm (diameter*height)
  • Battery Model: CR1632 (Replaceable Battery)

Built-in sensors

  • Sensor operating temperature: – 40 ~ 125 C
  • Pressure monitoring range: 0-13 Bar (188 Psi)
  • Pressure accuracy: +0.1Bar(1.5ps)
  • Temperature Accuracy: +3 C
  • Transmitting power: <10dBm
  • Transmitting frequency: 433.92MHZ
  • Battery life: > 5 years
  • Sensor mass: 78-98g
  • Battery model: CR2450HR
